Factory Price! Electric Scissor Hydraulic House Stair Lift Elevator Platform

Specialized inFactory Price! Electric Scissor Hydraulic House Stair Lift Elevator Platformand related product development and production

Samples: Available / Stock: Sufficient

Estimated delivery time: 3-5 days

Product Parameters

Basic Info.

Model NO.

HS0507E

Application

Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane

Lift Mechanism

Scissor Lift

Carrying Capacity

Weight Level

Moves

Self-propelled

Driven Type

Running Mode

Moving

Feature

Explosion-Proof, Insulating

Certification

GS, CE, RoHS, ISO 9001, Spillover Valve

Platform Capacity

230kg

Max.Drive Speed (Stowed)

4km/H

up/Down Time

25/20s

Control

Switch

Transport Package

High Quality Paper Boxes with Stretch Film

Specification

1.53m * 0.81m * 2.11m

Trademark

HERED

Origin

China

HS Code

8428909090

Production Capacity

20, 000 Sets /Year

Packaging & Delivery

Package Size

153.00cm * 81.00cm * 211.00cm

Package Gross Weight

995.000kg

Product Description

Online consultation to get the lowest price

House Stair Lift Elevator Platform Electric Scissor Hydraulic Lift Price

1. Optimized matching, high cycle times, better endurance.
2. Precise control greatly improves the smoothness of operating.
3. Large ground clearance, stronger passability

MODEL	HS0507E
Max. Working Height(In/out)	6.6m/0m
A-Max. Platform Height(In/out)	4.6m/0m
B-Platform Length	1.35m
C-Platform Width	0.7m
Extension Size	0.6m
D-Heights (Rails Up)	2.11m
Height (Rails Down)	1.77m
E-Length (with Ladder)	1.53m
F-Overall Width	0.81m
G-Wheel Base	1.11m
H-Clearance (Stowed)	0.05m
I-Clearance (Raised)	0.02m
PERFORMANCE
Platform Capacity	230kg
Extension Capacity	113kg
Max. Occupancy(in/out)	2/0
Max.Drive Speed (Stowed)	4km/h
Drive Speed (Raised)	0.5km/h
Turning Radius (Out.)	1.7m
Up/Down Time	25/20s
Gradeability	0.25
Max. Slope	1.5°/3°
Control	Switch
Drive	RWD
Multi Disc Brake	Rear
Max.Wind Speed	0m/s
Tires (mm)	305X100mm
POWER
Batteries (V/Ah)	24V/100Ah
Charger	100-240VAC/6.3A
WEIGHT
Weight	995kg

House Stair Lift Elevator Platform Electric Scissor Hydraulic Lift Price

Our Advantages

Technology R&D Advantage

With a 200-person R&D team, 58 national patents (including 12 invention patents), and a "Intelligent Lifting Technology Laboratory" co-founded with Shandong University School of Mechanical Engineering. Annual R&D investment accounts for 8% of sales, ensuring technology leads the industry by 3-5 years.

Production Process Advantage

Adopting robot welding (weld strength increased by 30%), shot blasting rust removal (rust removal grade up to Sa2.5), electrostatic spraying (coating thickness 80-120μm, salt spray resistance test up to 1000 hours), equipment service life extended to more than 15 years.

Customization Capability Advantage

We can customize the table size (1-10m), lifting height (1-20m), load (3-100 tons) according to customers' requirements, and support the installation of explosion-proof devices, remote monitoring system, non-slip table and other special configurations, and provide 3D design solutions within 72 hours.

FAQ

How long is the warranty?

3-year warranty for the whole machine, 5-year for core parts (hydraulic system, motor included).

How long for custom orders?

7-15 workdays (varies by complexity); initial proposal ready within 12 hours.

How long is international shipping?

15-30 days via DHL/COSCO; full tracking provided throughout.

How fast is after-sales response?

Queries answered within 12 hours; urgent issues (e.g., failure to lift) get on-site support within 48 hours.

Do you provide installation?

Free on-site installation in China; overseas orders include video guides, with paid engineer dispatch available.

What payment methods are accepted?

T/T, L/C for international orders. 30% deposit required for custom models, balance paid before shipment.

What scenarios is it suitable for?

Factories (loading/unloading), construction (aerial work), logistics (container handling), warehousing (equipment maintenance).

Are there international certifications?

CE, ISO 9001 certified—compliant with EU and global industry standards.

Mode of Transportation

Departing from major ports, FCL/LCL transportation, providing door-to-port (DAP), port-to-port (FOB) services, including export customs declaration and commodity inspection procedures

Land transportation: For neighboring countries in Central Asia and Southeast Asia, cross-border truck transportation, arriving in 15-20 days

Air freight: Urgent orders can be delivered by international air freight (such as DHL Aviation) in 7-10 days, suitable for small customized parts

WHY THEY SAY TO US

"CE certification made import easy. Lifting precision (±0.5mm) matches our production line needs. Saved 30% on manual labor costs."
Hans Mueller

Plant Manager at German Auto Factory
"8 fixed platforms installed 18 months ago. Rust-resistant coating still looks new. Their engineer visited twice for free maintenance checks."
Priya PatelOperations Head at IndiaWarehousing Group
"Our 5 mobile lifting platforms have been running 12 hours daily for 2 years—zero breakdowns. The after-sales team responds in 6 hours when we need parts."
Michael Thompson
Logistics Director at EuroWarehouse

Request A Free Quote

✅ After submitting the form, a dedicated technical consultant will be arranged for docking within 1 hour

✅ Provide free on-site survey and equipment selection suggestions

✅ Enjoy 3-year free maintenance service after purchasing the equipment

✅ Global 24-hour after-sales service hotline, response time no more than 2 hours
